Construction

• Forward hull compartment foam filled for added strength and noise dampening where possible


• Hand laid-up, molded fiberglass hull, deck and flybridge, with core in decks, cabin top, flybridge andamp; hull sides


• Independent compartments throughout hull


• Isophthalic gelcoat exterior (white)


• Quality gelcoat finish to center walkway area of Engine room for ease of maintenance


• Solid reinforced GRP keel, chines and hull bottom through engine room


• Vinylester resin in first outer layer of hull


• Watertight collision bulkhead forward

General Specifications

• All exterior stainless steel mirror finish with ground and polished welds 316 marine grade


• Antifouling: 2 coats epoxy undercoat, 2 coats antifoul (black), prop speed on props, rudders andamp; metal work


• Dyson and#39;Multi floorand#39; cordless rechargeable vacuum cleaner with


• detachable long-reach wand


• Fender Covers with R logo x 4 (Black)


• Fenders x 4, dock lines x 4 and boat hook, 1 x ball fender


• Fire extinguishers, portable x 6


• Gelcoat 1 liter x 3, shipped on board


• Molded non-skid gelcoat deck surfaces


• Owners manual high quality and comprehensive


• Safety labels – English language


• Trigger hose x 3, for use with deck washdowns

Mechanical

• Acoustic andamp; thermal insulation to Engine room


• Air conditioning 12,000 BTU reverse cycle, for cooling and heating to utility room andamp; day head


• Airconditioning combined modulating andamp; direct expansion system with individual cabin controls for cooling and heat, total 166,000 BTU condenser units 48,000 x 1, 36,000 x 1, 24000 x 1, 16,000 x 2, 10,000 x 2, 6,000 x 1 BTU


• All through hull fittings on or below the water line fitted with ball valves, all hoses double clamped


• Bilge pumps auto andamp; manual override x 8 (incl. emergency pumps mounted higher x 2)


• Bow thruster with emergency bilge pump, controls to helm – EJS system, hydraulic bow thruster, connected to Twin Disc quickshift gearboxes inc. 3 joysticks (1 x fwd helm, 1 x port side rear FB, 1 x cockpit)


• Emergency rudder locking pins


• Engine deck hatch (above) insulated andamp; removable in case of major engine work


• Engine mounts - anti vibration


• Engine room, lazarette, fwd. bilge, lighting DC / LED


• External andamp; internal seawater strainers for main water intakes engines, generator x 2 andamp; air conditioning


• Fiberglas aqualift exhaust system for generator with water separator x 2


• Fiberglass exhaust system for engines with underwater outlet and bypass above waterline


• Fire suppression system for engine room with automatic/manual controls


• Fresh water heater (AC) 2 x 75L (19.8 Gal Each)


• Fresh water pump AC, secondary backup pump (switched independently) DC


• Fresh water system (pressurized) capacity 850 litres (224 US gallons) approx. with gauge in Czone


• Fresh water tap andamp; hose set in engine room


• Fuel filters water separator for engines andamp; generator (dual to main engines)


• Fuel lines all swaged


• Fuel shut-off valves


• Fuel tank gauge to CZone andamp; at deck filler


• Long Range Fuel tanks, GRP coated in fire retardant resin. 2 x wing tanks, each approx. 3,500L, total 7,000L (1,849 US gal.).


• 1.5” balance line with manual valve control for balancing when filling. 1 x tank 3,300 (871 US gal.)


• Total 10,300L (2,720 US gal.) with 2 x transfer pumps (port andamp; starboard) under floor


• High pressure water cleaner plumbed to outlets at FB, bow and cockpit (supplied with 1 x 15metre (49’3”) hose and spray wand)


• Holding tank (GRP) capacity 600Litres (158Gallons)


• Lazarette fan forced ventilated


• Non slip rubber matting fitted between engines


• Oil change system main engines, gearboxes andamp; generator x 2


• Polished stainless grab rails to engine room


• Propellers x 2, nibral five blade, CNC processed, dynamically balanced


• Sanitation system with control at helm for overboard pump out and deck fitting for dockside pump out


• Shafts AQUAMET 22 (x2) oil filled shafts, struts, glands


• connect to Twin Disc remote mounted Quickshift gearboxes, inc. EJS joystick system, hydraulic bow thruster


• Steering Hydraulic with electronic steering helm


• Trim Tabs, electric interceptor, with position indicators integrated into controls at helm (auto trim system)


• Venting dorade system for engine air intakes with mist eliminators and fan


• Walk in engine room from crew / utility room. 2nd access from cockpit for mechanics, oils andamp; tools


• Water filter (charcoal) to galley tap and icemaker (fitted inline)

Superstructure

• Enclosed flybridge 4 sides GRP double moulded hardtop with vinyl covered head lining. Fixed tempered glass front and tinted opening side windows (clear windows for European boats). Opening s/s framed rear door and awning window, deck hatch access from rear deck onto hardtop for service


• Sunroof fitted to flybridge hardtop with electric open and close, glass / alloy Webasto inc. screen andamp; blind


• Targa (GRP wing) on hardtop including light mast, aerials for stereo andamp; VHF 8and#39; mounted to flybridge hardtop


• Hardtop and targa painted in Tungsten silver, standard and optional electrical hardware painted black where possible including radar and mounts, domes, light mast, aerials for stereo andamp; VHF and searchlight

Electrical

• Alternators x 4 independent start banks x 2 and independent house bank and auxiliary bank


• Batteries (maintenance free) independent 24V port andamp; starboard start (total x 4), auxiliary 24V (total x 2), flybridge 12V (total x 1), house 24V – 3x 24V 6000Wh (690AHr


• Total/552AHr Usable Li-Ion bank)


• Battery banks individually isolated


• Battery chargers automatic, 30Amp/24VDC for start and auxiliary, 100A/24VDC for house and 25A 24/12V DC/DC converter for 12V FB battery charge


• Battery paralleling system for emergency engine starting


• Bonding system, to all metallic hull fittings under the water line with zinc anode including galvanic isolator


• CZone - Configuration for iPad connectivity. Includes programming and WiFi interface includes iPad andamp; iPad dock in master cabin


• Digital monitoring system including AC and DC power metering, fluid tank level monitoring and DC circuit status via colour LCD touchscreen displays, mounted at helm , Saloon andamp;


• iPad dock to master stateroom


• Engine monitoring including instrumentation, alarms and hour meters


• LED Lighting throughout boat where applicable


• Light switches with Blue backlighting.


• Navigation lights LED (international standard)


• Wiring coded, numbered andamp; assembled in looms where possible


• Generator Onan EQD 29kw/60Hz with muffler, water separation system, fresh watercooling including sound shield, remote stop / start electronic, hour meter


• Generator, Backup – 17kw/60Hz inc. changeover. Can run optional gyro, selected air con, entertainment, ice maker, battery charger 24V system to Start.


• Inverter 4kw for AC supply to A/V systems, icemaker, lights, winecooler, F/Water pump and AC outlets

Electrical – Audio / Visual

• Port cabin 24” LED TV, Fusion Apollo 670 Stereo with FM,


• Bluetooth, Airplay and Partybus, 2 x Fusion Speakers


• Cockpit Mezz fold down 32” LED TV, 2x speakers, 2nd zone from saloon Yamaha


• Flybridge 32” LED TV, Fusion Apollo 770 Stereo with FM,


• Bluetooth, Airplay and Partybus, 6 x JL Audio Speakers


• Flybridge cameras to saloon, bow anchor, cockpit andamp; Engine room with feed to navigation screens (integration with electronics owners option)


• Foredeck stereo 12V AM/FM/USB/AUX/iPod/iPhone/Bluetooth, 4 speakers.


• Fwd cabin 32” LED TV, Fusion Apollo 670 Stereo with FM, Bluetooth, Airplay and Partybus, 2 x Fusion Speakers


• Master stateroom 40’’ LED TV, Bluray player and home theatre system including 5 speakers and sub woofer


• Saloon 50’’ LED TV, home theatre system and Bluray player including amp andamp; sub woofer, 5 speakers in saloon and 2 speakers to cockpit (powered from inverter)

Alfresco Dining

• Mezzanine area seating - 2 x L shaped Sunbrella covered lounges, 2 x gloss finished folding tables, top load cool box with adjustable plates under AFT mezzanine seat bases.


• Lights under seat bases, storage under seats. Teak floor to all of the mezzanine. 2 x S/S support poles and used for drainage


• Bar area outside hopper window, timber clad, includes glass door bar fridge, swing in style bar stools x2, grabrail and solid surface benchtop (benchtop colour to match galley selection, stool colour to compliment exterior lounge selection)


• Feature one way glass paneling to qtr panels


• Portside folding down TV from overhead


• Rear saloon hinge out doors andamp; opening up window frame in polished s/s, (tinted, tempered glass), Inbuilt manual pull down blinds in hopper windowandamp; doors


• Mezzanine quarter panel clear in plexiglass

Deck / Cockpit

• Anchor chain built in seawater wash system, remote to FB main helm


• Anchor chain chafe plate fitted to bow sprit


• Anchor lockers on foredeck, starboard side hatch access anchor chain and storage, Portside hatch storage bin


• Anchor s/s 80kg (1176lbs) anchor (Ultra), 100m (328ft) of


• 13mm (1/2’’) galvanised chain, Ultra swivel andamp; cruise safety strap, safety harness securing eye bolt to foredeck


• Anchor winch vertical with overload protection, suits rope andamp; chain, up andamp; down hand held remote andamp; remote control incorporating chain counter to helm at FB, manual handbrake


• Bow rail welded s/s (316 marine grade, highly polished) with mid safety wire including flag staff and burgee (bow flag)


• Bow roller stainless steel self-loading through bowsprit, heavy duty


• Cleats stainless steel, 13’’ (x10), hawse holes (x2) and popup fender cleats (x2), fairleads at bow (x2)


• Cockpit floor reinforced with alloy plate for future game chair or table fitting (x2)


• Cockpit hatches with heavy duty s/s lock downs and gas struts for lazarette storage and bilge access


• Cockpit side coaming lockers fitted for storage (double moulded)


• Davit ADC 550kg low profile boom, hydraulic luffing, slewing, electric winch


• Double action manual bilge pump for engine room and lazarette with Y valve


• Engine room access hatch (lockable)


• Fish bins insulated (x2) in cockpit floor with pump out facilities


• Foredeck plug (for use with a tender battery charger)


• Foredeck storage lockers port and starboard side including fender locker


• Hand held shower hot andamp; cold (fresh water)


• Lighting to cockpit includes courtesy (LED) and flood lights


• Rub rail impact and UV resistant PVC (white) with stainless


• Self draining cockpit to the stern


• Steps to side decks port andamp; starboard, illuminated in blue LED light around walk around decks


• Tackle box lockers (GRP)


• Toe kick created by moulded GRP cover boards to cockpit coamings


• Transom door GRP opening outwards x 2 with fold over bridges


• Transom storage unit top loading, drained with glass window,


• 2 x lockers (port andamp; stbd) in transom, storage to stbd locker, manual bilge pump located in port locker


• Triangular quarter glass clears to cockpit port and starboard with additional grab rails (strataglass no tablings)


• Wash down – High pressure water cleaner with outlets at foredeck and cockpit (fresh water) includes non marking hose and spray wand


• Wash down outlet to cockpit and foredeck (fresh water) with quick disconnect


• Wash down outlet to cockpit and foredeck (sea water) with quick disconnect


• Wet bar with 1 x electric BBQ/sink beside, 2 storage lockers above BBQ and Cockpit Freezer. 2 x rubbish bins below bbq. Lift up hatch to engine room access with gas struts andamp; S/S access ladder. Portside cockpit freezer with 2 x Waeco plates

Deck Finishes Exterior

• Alfresco mezzanine – teak laid in steps from cockpit


• Cockpit floor GRP – nonskid


• Cockpit floor, integral to deck (fully moulded) with alloy plate for future game chair or table fitment


• FB rear deck – teak decking


• Side decks andamp; fwd. deck – GRP nonskid

Saloon

• Air conditioning 48,000BTU (2x 18,000 andamp; 2x 6,000) reverse cycle, for cooling and heating


• Carpet with underlay (forward section of saloon)


• Dinette table, folding both ends, twin electric high/low pedestal with table slider (athwartships)


• Dinette, L-shaped, in premium leather with storage underneath


• Electric blind to saloon / galley (port andamp; stbd)


• Feature upper pelmets with lighting


• Head lining, vinyl with padding


• Lighting, overhead (LED)


• Lounge, premium design portside with storage under.


• Ottoman andamp; coffee table reversible, with magazine storage


• Pantograph side opening door portside for quick and easy access to side decks


• Removable black breezeway cover outside


• Side windows opening tempered, tinted glass, (single sliding window)


• Staircase to flybridge, varnished Walnut treads (nonslip top surface)

Saloon - Galley

• Aft galley arrangement


• Appliances integrated into joinery


• Built in overhead storage lockers with positive locking hardware


• Combination oven/microwave with integrated grill


• Dishwasher (premium brand)


• Flooring, vinyl (Premium grade) fitted to galley only


• Induction cooktop, 3 element


• Large garbage bin to starboard entryway


• Large pull out drawers to forward face of galley with commercial grade runners


• Large pull out panty stbd side with commercial grade runners


• Lighting, overhead (LED)


• Pot holder over cooktop s/s removable


• Rangehood (premium brand)


• Refrigeration, 2 x two drawer fridge/fridge units andamp; 1 x two drawer freezer/freezer unit under bench (DC)


• Solid surface benchtop with s/s sink by 1and#188; and cover x 2, including garbage bin


• Storage cabinets andamp; drawers below and above bench


• Water filter fitted inline to cold water tap

Forward Deck

• Flybridge brow landing access ladder, removable in stainless steel

Flybridge

• Aft flybridge GRP guard rail with integrated space for future safety equipment locker outboard faces painted tungsten silver to match hardtop

Port Stateroom

• Air conditioning: 10,000 BTU reverse cycle


• Bedside table with drawers


• Carpet with underlay


• Hanging locker, cedar lined, shoe shelf, with auto lighting (LED)


• Port light fixed bonded glass recessed into hull side (x1), with manual blinds


• Porthole (x1) opening round with alarm to helm, s/s and flyscreen


• Private entrance door


• Reading and overhead lighting (LED)


• Side by side berths with electric sliding mechanism to form


• double bed (innerspring mattresses) with storage under berths


• Storage cabinets outboard with positive locking

Full Beam Master Stateroom

• Feature bedhead


• Access to private ensuite


• Air conditioning: 18,000 BTU + 6,000 BTU reverse cycle, heat (incl. ensuite head)


• Bed side tables (x2) with storage


• Carpet with underlay


• Feature lighting (LED)


• Hanging locker, cedar lined with auto lighting (LED) x 2, with shoe shelf, full length hanging plus shelf


• Port light fixed bonded glass recessed into hull side x 2 with manual blinds


• Port side drawer unit with writing bureau featuring timber top with leatherette inlay and concealed mirror lined makeup case storage, also includes power point with USB outlet forlaptop, includes dinette style seat and book storage.


• Portholes (x2) opening round to master cabin head (x1), master cabin (x1) with alarm to helm, s/s and flyscreen


• Reading, overhead and courtesy lighting (LED)


• Safe for valuables fitted to hanging locker (port side under shelf)


• Storage area with drawers under island berth – king size, incl. gas assisted lift for the bed to bulk storage and latex mattress

Starboard Stateroom

• Air conditioning: 8,000 BTU, reverse cycle


• Bedside table fwd of lower bunk with drawers


• Drawers and cupboards for storage


• Hanging locker, cedar lined, with auto lighting (LED)


• Port light fixed bonded glass recessed into hull side (x1) with manual blinds


• Porthole (x1) opening round with alarm to helm, s/s and flyscreen


• Private entrance door


• Reading and overhead lighting (LED)


• Single bunk (x2) with innerspring Mattresses (storage under lower bunk)

Forward Stateroom

• Access to private ensuite


• Air conditioning: 16,000 BTU with reverse cycle heat split to ensuite


• Carpet with underlay


• Feature bedhead


• Fixed hull windows fitted port and starboard in tinted tempered glass including manual blinds matching saloon selection


• Hanging locker, cedar lined to port with auto lighting (LED) and cedar lined storage locker to starboard with shelving


• Hatch - white with OceanAir flyscreen and block out blind


• Private entrance door


• Queen walk around berth with mattress, lifts up with gas struts for storage space and drawers underneath


• Reading, overhead and courtesy lighting (LED)


• Storage cabinets outboard with positive locking hardware

Companionway

• Flooring, companionway landing in premium grade vinyl


• Handrail to companionway stairs


• Hatch in companionway floor to forward pump area


• Wine cooler under stairs at entry to master cabin


• Lighting courtesy


• Linen cupboard with drawers at bottom

Utility Room andamp; Day Head

• Access to engine room via utility room watertight entry door


• Additional access to engineering components under stairwell


• Air conditioning: 10,000 BTU reverse cycle


• Courtesy lighting to stairwell treads (LED)


• Entranceway to utility room/crew head lined with water resistance panelling andamp; Gelcoat finish, incorporates storage cabinets and access to galley bin and main switch panels


• Exhaust fan in day head


• Gel coat lined


• Lighting, overhead and vanity (LED)


• Mirror above day head vanity


• Opening porthole (x1) with alarm to stbd side utility room


• Premium grade vinyl flooring with solid surface flooring to head


• Private entrance door


• Single length towel rail in day head


• Solid surface benchtops with underslung built in basin


• Storage under day head benchtop


• Toilet roll holder andamp; accessories


• Washer /Dryer cabinet


• Wet crew head shower stall with curtain, automatic shower sump pump, shower head


• Icemaker (Hoshizaki) located at top of stairwell to mezzanine

Heads – Master, Guest, andamp; Day

• Air conditioning, reverse cycle (split from staterooms)


• Exhaust fan


• Flooring through heads andamp; shower stall in solid surface


• Lighting, overhead and vanity (LED)


• Master head with holding tank level indicator


• Toilet, fresh water flush


• Mirror


• Opening portholes with alarm to helm (x3) from heads and manual blinds


• Private entrance door


• Shower stall with glass partition, frameless glass door, automatic sump pump, rain shower head and separate shower head hand held


• Single length towel rail (2 per head) (Master andamp; VIP have DC heated towel rails)


• Soap dispenser to vanity basins


• Solid surface benchtops with underslung built in basins


• Storage under and above benchtops


• Toilet roll holder andamp; accessories


• Vanity cabinet and mirror above sinks

Enclosed Flybridge

• Aft flybridge stainless overhead grab rail


• Air conditioning: 18,000 (x 2) BTU with reverse cycle. Outlets at helm, windscreen demister and at aft flybridge


• Blinds and internal window covers to side windows and windscreen


• Deck hatch to hardtop aft


• Enclosed flybridge 4 sides with separate aft deck area including aft flybridge access door


• FB aft docking helm, Electric steering, S/S wheel inc. electronic controls, stop/start panel /dual lever engine controls, horn, VHF remote, joystick (x1) and dash cover


• Flooring to internal flybridge sole in high quality premium grade vinyl


• Grab rails, stainless steel, conveniently located


• Head lining: vinyl with padding


• Lighting: overhead, courtesy, red night light and flood lights to cockpit (LED)


• Lounge (Lshape interior) upholstered in premium quality leather including fold out double bed and bedding


• Lounge on aft deck (aft facing) with Sunbrella upholstery, teak table folding on fixed height pedestal


• Ottoman to lounge area (colour to match flybridge upholstery) andamp; coffee table reversible on rubber feet


• Rear flybridge door and window frames in polished s/s, including rear door (sliding) and opening up rear window (tinted, tempered glass) to match saloon. Inbuilt manual pull down blinds in hopper window andamp; doors (x2)


• Refrigerator drawer inside


• Sunroof in hardtop with electric open and close. Webasto, glass inc. screen andamp; blind, 3M heat film /tinted inside glass


• Wet bar with solid surface bench top, underslung sink with mixer tap and drawers for glass storage, icemaker, s/s fridge drawer


• Windows, fixed tempered glass, curved front, opening tinted sides (Note clear for European boats) FW, 3M heat film / clear inside glass


• Windscreen wipers x 3 pantograph, heavy duty with intermittent control settings (includes fresh water washers)

Helm

• Autopilot with control to main helm (Brand to compliment Navigation package selection)


• Cameras to saloon, cockpit and engine room with feed provided to flybridge dash for future integration with electronics


• Chain counter (anchor)


• Compass, 4.75and#39;and#39; with light


• Drink holders (x2)


• Electronic engine control unit, twin lever gear andamp; throttle


• Fuel, water and holding tank monitoring to helm with holding tank pump out controls via Czone screen and independent switch


• Helm and companion chairs, fully adjustable (master with electric adjustment) including folding arm and foot rests, upholstered black


• Helm electronics area with 12/24VDC feed, main circuit breaker protected


• Intercom to galley and engine room


• Main helm Electronic steering, Twin Disc quickshift controls,


• EJS joystick. Wipers x 3, self park, fresh water washdown


• Searchlight on hardtop, remote control at helm


• Steering wheel - luxury leather bound


• VHF radio with hailer and remote to aft helm position (including 8and#39; aerial)

Electronics

• A comprehensive range of factory fitted electronic packages and custom fitments are available through Riviera Australia, from fish finders, to underwater lights. Contact your dealer for details.


• Autopilot


• Camera systems


• Charting system


• Entertainment system


• Fishfinder


• Inverter


• Radar


• Satellite TV and communication systems


• Searchlight


• Spot, flood and colour change lighting


• Underwater lighting

Regional Specification Americas

• AC power outets (doubles) to heads, galley, cockpit and engine room


• Boat is built to comply CE CAT B


• Outlets with Ground Fault Circuit Interrupter (GFCI) protection


• Shore Power electrical inlet, 2 x 50A 125/250V


• Shore Power lead, 2 x Glendinning Cablemaster, 60 foot inc wireless remote (110/220V/50 amp)


• Vessel AC system built to 110/220V/60Hz


• Single AC power outlets with dual USB outlets to staterooms
